Hydro Tek Self-Contained Filtration - AZV55
Trailer/Truck Bed Mounted Self-Contained Filtration
AZV55 12 gpm Recovery - 5 gpm Process
Protecting the environment from wash water runoff and complying with governmental storm drain regulations is simple, economical and effective with the AZV Series. The AZV vacuum recovery and filtration system provide 7 stages of filtration with up to 5-gpm continuous five-micron processing of wastewater where soaps and other chemicals are not used.
Wastewater is recovered through a vacuum scupper to eliminate run-off. Recycled water is pumped back to your bulk water tank for reuse to power wash concrete or other flatwork or diverted to landscaping or sewer as permitted. Heavy solids are collected in the V-section of the tank and are easily removed through a quick purge dump valve.
When combined with a Hydro Tek SC or SCU Series washer and ProTowWash® trailer or tank skid, you have a complete self-contained mobile wash, recovery, and recycle unit. The system is the choice of professional cleaners to protect the environment, conserve water, and comply with EPA storm drain requirements. (For use with cold water or hot water up to 200°F)
Complete system includes: 50’ vacuum hose, scupper and containment berms.
Features
- Vacuum Recovery Rate 12 GPM
- Wastewater Process Rate 5 GPM
- 5 Micron finish processing
- Automatic Pump Out, transfers water while pick up continues without interruption
- Reusable and Replaceable filter cartridges
- Seamless Purple Polyethylene Hopper complies with California Title 22 recycled non-potable water identification requirements
- Continuous pickup, while simultaneously pumping out – no pickup interruption
- Simple to run with automatic pump and vacuum controls.
- Easy to maintain with replacement filters and new lift-out basket strainer.
- Conserve water supply by reusing water to clean concrete and other flatwork.
- Pump out bypass allows transfer of water directly to landscaping or sanitary sewer, instead of to your bulk tank, as permitted.
New updates for the Hydro Vacuum AZV and RZV mobile water recovery filtration systems. This update is regarding filter changes and vacuum housing.
>The first update is the change to a lift-out 800 micron strainer basket to replace the debris bags as stage one of the filtration process. This strainer basket can swiftly be dumped & rinsed when full to get the user back to work right away and eliminates the need to clean or purchase replacement filter bags.
The next update is the change from both the pleated and carbon filters to a pair of new string wound filters. String wound filters are effective in removing sediment which is the type of filtering needed by the majority of pressure washer users. These filters will last longer on typical pressure washing jobs resulting in a lower cost of ownership. The new string wound filters are now being stocked and can be ordered for previous models of AZV or RZV filtration units, too. There may be an occasion where a user may require the original pleated and carbon filters so those filters will still be available.
The third update is the change to an all stainless, rustproof vacuum chamber and housing. In addition, there is a drain added (see photo d) to be able to drain any water that may get trapped in the vacuum chamber
>*PRICING TOO LOW TO ADVERTISE ONLINE, JUST CALL IN 855-351-9274
AZV55 |
AZV88 | |
---|---|---|
Technical Data | Vacuum Pick-Up System | |
Vacuum Motor | 104 CFM, 2 Stage motor, 91” lift, recovers 12 gpm, enclosed in a rustproof stainless housing | |
Vacuum Power | Powered by SC Series pressure washer Generator (120v / 8.6amp) | |
Barrier | 1) 6’ Rubber, Sand Filled Berm, 2) 10’ Sand Dam Tubes – sand not included | |
Hose | 2” x 50’ Spiral Vacuum Hose with scupper attachment |
AZV55 |
AZV88 | |
---|---|---|
Technical Data | Separator Tank | |
Hopper | Polyethylene Seamless Molded, Slant Cone Bottom, 40-gallon capacity | |
Oil/Solids Separation | Center water column gravity separation with 1½ ” sludge/solids drain – 5-gallon capacity | |
Mounting | Factory-installed and wired on Hydro Tek trailer (dealer-installed on truck or existing trailer) |
AZV55 |
AZV88 | |
---|---|---|
Technical Data | Filtration - 6-Stage | |
Transfer Pump | 4.9gpm 45psi Triplex Diaphragm with pressure shutoff and automatic level control, ¾” hose | 8gpm 25psi Centrifugal pump and automatic level control, 1” hose |
Pump Power | Powered by washer battery (12vdc / 13 amp) Circuit Breaker Protected, Lighted on/off switch | Powered by washer battery (12vdc / 20 amp) Circuit Breaker Protected, Lighted on/off switch |
Inlet Filter | Basket strainer mounted inside separator tank, easy lift-out design | |
Final Filter | 1) 5 Micron Polyester Felt Bag 7” x 32”, mounted on lid in storage tank | |
Oil Skimmer | 8” x 24” Absorbent Skimmer included, (use on ground at scupper to collect oil) | |
Filter Canister 1 | 50-micron string wound filtering material | |
Filter Canister 2 | 20-micron string wound filtering material | |
Warranty | One year accessory warranty | |
Dim/Weight | 19.5” x 28” x 42” / 132 # dry weight |
