SS Series Hydro Tek Hot Water Skid 4.8@3000 #SS30005VH
SS Series Hydro Tek Hot Water Skid #SS30005VH
12v 4.8gpm @ 3000 psi, 479CC Vanguard Engine, 250 degrees, General Pump
When electricity is not available and high power cleaning is needed, the SS Series pressure washer provides the solution. The commercial duty gas or diesel engine provides the power to both the pump and the diesel-fired burner, for hot water, high-pressure cleaning at remote sites. The rugged frame can be trailer mounted or can be rolled through a standard doorway with its optional wheel kit. An invaluable power washer for property management companies, contractors, farmers, mechanics, or anyone who requires a mobile solution to dirt, grease, and grime.
Hydro Tek’s unique “Pro-tect-it” frame of 1¼”, heavy-gauge steel, with durable electrostatically applied powder coat finish, can be truck or trailer mounted, pulled with the optional wheel kit, or left as a stationary skid.
Stainless Steel Panels
These rugged and durable panels offer lifetime rust and corrosion resistance and protection of your valuable investment from the harshest environments. Keeps your machine looking like new for years to come.
Simple to Use Controls
Lighted rocker switch, thermostat and other controls are located on an easy to reach recessed panel to prevent damage.
Efficient OHV gas engines with electric key start, low oil shutdown, and cast iron cylinder for maximum duty and performance. Some models equipped with a durable diesel engine for enhanced longevity and efficient operation.
Heavy Duty “roto-molded” rust free fuel tanks with fuel filter to protect against contaminated fuel. Extended run time (up to 8hrs.) eliminates interruptions.
Frame Mounted Unloader
The unloader is frame mounted eliminating heat failures and vibration. Low flow models have pressure activated unloaders for consistent and dependable operation. Higher flow models have flow activated unloaders which allow pressure to build up gradually as trigger gun is activated eliminating “pressure spikes” and improving operator control and safety. When the gun is released, entire system pressure is relieved enhancing life of washer and eliminating engine starting problems.
The coil is a Hydro Tek manufactured SpiraLast™ heating coil. Robotically fused ½” schedule 80 steel pipe is cold rolled to protect the steel pipe from fatigue and the spiral coil is then surrounded by ceramic insulation and stainless enclosure with double-wall end caps. Check out our lifetime coil warranty.
Flexible, high intensity 12V Diesel Burner System
Sophisticated 12V burner system transforms available power from system to fire the diesel burner. This efficient burner system, with PowerLight ignitor, provides maximum burner performance. No outside power source is required. (See SCX Series for a few additional 12v skids.)
Belt Drive or Direct Drive Pump
These industrial triplex, ceramic plunger pumps are run at lower RPM to give maximum efficiency and longevity outperforming the competition. Pumps are located front and center for easy access. Belt drive models have the EZ Align™ belt tensioning system to allow for easy, single bolt, belt tensioning adjustments.
More Standard Features
- Burst disc technology for operator safety
- Adjustable temperature up to 250ºF with steam setting (SS30008HG is adjustable to 200º, no steam setting)
- Heavy-duty wand & gun with nozzle storage, 50’ high-pressure hose and quick release nozzles
- Slide-out, snap lid battery box
*PRICING TOO LOW TO ADVERTISE ONLINE, JUST CALL IN 855-351-9274
SS Series Direct Drive Models
|SS40004V||4000||3.5||250º F||479||Vanguard Gas|
SS Series Belt Drive Models
|SS30004VG||3000||3.8||250º F||479||Vanguard Gas|
|SS30005VH||3000||4.8||250º F||479||Vanguard Gas|
|SS30008HG||3000||7.3||250º F*||688||GX630 Honda Gas|
|SS35004VG||3500||4.0||250º F||479||Vanguard Gas|
|SS35005VG||3500||4.7||250º F||570||Vanguard Gas|
|SS35005VC||3500||4.6||250º F||570||Vanguard Gas|
|SS35006VG||3500||5.5||250º F||527||Vanguard Gas|
|SS35006HG||3500||5.5||250º F||688||GX630 Honda Gas|
|SS40005VH||4000||4.8||250º F||570||Vanguard Gas|
